D15/D17 Series (US) / G15/G17 Series (Metric)

Diaphragm Pump Features

Versatile, Reliable Pumps for a Wide Range of Applications

  • Pumps the full spectrum of low-to-high viscosity fluids.
  • Features a seal-less design and horizontal disk check valves that enable the pump to handle abrasives and particulates that might damage or destroy other types of pumps.
  • Simple, compact design reduces initial investment and lowers maintenance costs.
  • Operational efficiencies reduce energy costs.
  • Able to run dry without damage (or additional maintenance) to the pump in case of accident or operator error.
  • Tolerates non-ideal operating conditions.
  • Minimizes maintenance and downtime because there are no seals, packing or cups to leak or replace.

D15/D17 & G15/G17 Series Resources

D15 / D17 - Datasheets
Datasheets
D15/D17 Specifications
(Performance, Dimensions, Options, Ordering Information)
Application Worksheet
Installation Guidelines

G15 / G17 - Datasheets
Datasheets
G15/G17 Specifications
(Performance, Dimensions, Options, Ordering Information)
Application Worksheet
Installation Guidelines

D15 / D17 Series (US)
D15 / D17 - Flow Capacities
Model@ max rpmpsibargpml/min
D15-X/D17-X14505003413.852.3
1450150010313.350.2
1450200013813.049.2
1150250017210.138.1
D15-E/D17-E17505003415.558.7
1750150010314.856.2
1450200013812.045.5

D15 / D17 - Delivery
Modelpsibargal/revliters/rev
D15-X/D17-X50034 0.00950.0360
1500103 0.00920.0346
2000138 0.00900.0339
2500172 0.00880.0331
D15-E/D17-E50034 0.00890.0335
1500103 0.00850.0321
2000138 0.00830.0314

D15 / D17 - Other Specifications
Maximum Discharge Pressure
Metallic Heads:1500 psi (103 bar) @1750 rpm
(D15-E & D17-E only)
2000 psi (138 bar) @1450 rpm
2500 psi (172 bar) @1150 rpm
Maximum Inlet Pressure500 psi (34 bar)
Maximum Operating Temperature
Metallic Heads:250 ̊F (121 ̊C) - Consult factory for correct component selection for temperatures from 160 ̊F (71 ̊C) to 250 ̊F (121 ̊C).
Non-metallic Heads:140 ̊F (60 ̊C)
Maximum Solids Size500 microns
Inlet Port1-1/4 inch NPT
Discharge Port3/4 inch NPT
Shaft Diameter1-1/8 inch (28.6 mm)
Shaft RotationReverse (bi-directional)
BearingsTapered roller bearings
Oil Capacity2.2 US quarts (2.1 liters)
Weight
Metallic Heads:145 lbs. (66 kg)

G15 / G17 Series (Metric)
G15 / G17 - Flow Capacities
Model@ max rpmpsibargpml/min
G15-X/G17-X14505003413.852.3
1450150010313.350.2
1450200013813.049.2
1150250017210.138.1
G15-E/G17-E17505003415.558.7
1750150010314.856.2
1450200013812.045.5

G15 / G17 - Delivery
Modelpsibargal/revliters/rev
G15-X/G17-X50034 0.00950.0360
1500103 0.00920.0346
2000138 0.00900.0339
2500172 0.00880.0331
G15-E/G17-E50034 0.00890.0335
1500103 0.00850.0321
2000138 0.00830.0314

G15 / G17 - Other Specifications
Maximum Discharge Pressure
Metallic Heads:103 bar (1500 psi) @1750 rpm
(G15-E & G17-E only)
138 bar (2000 psi) @1450 rpm
172 bar (2500 psi) @1150 rpm
Maximum Inlet Pressure500 psi (34 bar)
Maximum Operating Temperature
Metallic Heads:121˚C (250˚F) - Consult factory for correct component selection for temperatures from 71˚C (160˚F ) to 121˚C (250˚F).
Non-metallic Heads:140 ̊F (60 ̊C)
Maximum Solids Size500 microns
Inlet Port1-1/4 inch BSPT
1-1/4 inch NPT
Discharge Port3/4 inch BSPT
3/4 inch NPT
Shaft Diameter28.6 mm (1-1/8 inch)
Shaft RotationReverse (bi-directional)
BearingsTapered roller bearings
Oil Capacity2.1 liters (2.2 US quarts)
Weight
Metallic Heads:66 kg (145 lbs.)

D15 / D17 - G15 / G17 - 3D CAD Drawings
Files
D-15 w/Metallic Pump Head(Solidworks Part)
D-15 w/Metallic Pump Head(IGES File)
D-15 w/Metallic Pump Head(STEP File)

Valve Selection

Choose the valve for this Diaphragm Pump

C62 Pressure Regulating Valve

A Hydra-Cell D15/D17 Series pumping system uses a C62 Pressure Regulating Valve.
